Getting Started with Android SDK v4

Introduction

Mappedin SDK for Android helps you deliver the rich indoor mapping experience of your venue, designed in Mappedin CMS, inside your Android apps.

First, we will go through the basic concepts that will help you understand how the SDK works. Then we'll also go through the setup and usage of the Mappedin SDK for Android.

The Android SDK is simply a native interface to the Web SDK. The SDK is a dependency built using Kotlin, and it automatically handles any authentication, network communication, fetching of map data, its display, and basic user interaction, such as panning, tapping, and zooming. The SDK allows you to build your own interactions. You can render your own additional layers on top of the map that the SDK renders.

Mappedin Android SDK is supported on Android versions 8.0 and above

Concepts

• After the quick initial setup and configuration, the SDK renders the maps associated with the keys provided by you, inside an MPIMapView instance you created.
• The SDK allows you to render your venue's maps in 3D. The SDK pulls the most up to date data from our mapping CMS for all your points of interest within your venue.
• The SDK supports drawing navigation paths and providing instructions to and from any point of interest within the venue. Both accessible and non-accessible optimized routes are supported. You can build more functionality on top of this experience, such as searching or switching venues.

Further pieces of this guide give you more details about how to setup the SDK and customize it as per your liking.

Quickstart

Add Permissions

Add the following permissions to your AndroidManifest.xml above or below <application />.

Copy
<uses-permission android:name="android.permission.ACCESS_FINE_LOCATION" />
<uses-permission android:name="android.permission.ACCESS_COARSE_LOCATION" /> <!--only needed if displaying user location-->
<uses-permission android:name="android.permission.INTERNET" />

Ensure that hardware acceleration not turned off by setting it to true.

Copy
<application
    android:hardwareAccelerated="true"
/>

Add Application Dependency to Gradle

Add the Mappedin SDK dependency to your build.gradle. You can find the latest version in Maven.

Copy
implementation 'com.mappedin.sdk:mappedin:4.1.0'

Refer to our Github repository to view the sample app created by Mappedin developers to understand how to embed a map into your app.

Display the Venue

Create an MPIMapView

Next you will need to add an MPIMapView view in your activity_main.xml and give it an id mapView:

Copy
<com.mappedin.sdk.MPIMapView
        android:id="@+id/mapView"
        android:layout_width="fill_parent"
        android:layout_height="fill_parent"
        app:layout_constraintBottom_toBottomOf="parent"
        app:layout_constraintLeft_toLeftOf="parent"
        app:layout_constraintRight_toRightOf="parent"
        app:layout_constraintTop_toTopOf="parent" />

In your MainActivity.kt, add the following imports:

Copy
import com.mappedin.sdk.MPIMapView
import com.mappedin.sdk.listeners.MPIMapViewListener
import com.mappedin.sdk.models.*
import com.mappedin.sdk.web.MPIOptions

Get a handle for the map view in the activity_main layout:

Copy
override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)

    binding = ActivityMainBinding.inflate(layoutInflater)
    setContentView(binding.root)

    val mapView = binding.mapView
}

Load the Venue

loadVenue is a MPIMapView function that allows you to render the venue in your app by passing in an options object and an optional showVenueOptions object.

The options object contains your venue, clientId, clientSecret, optional headers etc. To get you started we’ve provided a Mappedin Id and Secret that has access to some demo venues. When you’re ready to start using your own venues with the SDK you will need to contact a Mappedin representative to get your own unique Id and Secret.

You can also pass in showVenueOptions to modify the properties of the map, including backgroundColor, firstMapId, labelAllLocationsOnInit (whether labels appear), backgroundAlpha, on the first load. The following sample code shows an example of how to use it:

Copy
// use loadVenue to load venue
mapView.loadVenue(
    MPIOptions.Init("5eab30aa91b055001a68e996", "RJyRXKcryCMy4erZqqCbuB1NbR66QTGNXVE0x3Pg6oCIlUR1",
    "mappedin-demo-mall",
    headers = listOf(MPIHeader("testName", "testValue"))),
    MPIOptions.ShowVenue(labelAllLocationsOnInit = true, backgroundColor = "#CDCDCD")
)

showVenue is an alternative method to load the venue without using any API calls to retrieve the data. Instead, the data must be passed into the showVenue method which takes in a data string (which can be retrieved from a file).

Use this sample JSON file to get started with the showVenue method.

Here is an example:

Copy
// use showVenue to load venue
val venueDataJson = application.assets.open("mappedin-demo-mall.json").bufferedReader().use {
    it.readText()
}
mapView.showVenue(
    venueDataJson,
    MPIOptions.ShowVenue(labelAllLocationsOnInit = true, backgroundColor = "#CDCDCD")
)

Result

You should see something that looks like this in the Android Emulator:

And zooming in to have a closer look:
